10
American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781
Phase 4 OPL UniSport ® Microprocessor Control Panel Assembly
Illus. No. Part No. Qty. Description
1 800057 1 OPL Microprocessor Control Panel ONLY
865106 1 Phase 4 OPL UniSport ® Direct Spark Ignition (DSI) Non-Reversing Control
Panel Assembly Complete
(includes illus. nos. 1 through 8)
865105 1 Phase 4 OPL UniSport ® Direct Spark Ignition (DSI) Reversing Control
Panel Assembly Complete
(includes illus. nos. 1 through 8)
2* 306052 1 Electrostatic Shield
3 150108* 4 8-32 x 1/2” Pan Head Machine Screw
152001 4 8-32 Hex Nut
4* 153000 4 #8 Steel Burr
5* 137011 4 8/32” Aluminum Standoff
6 160005 1 Turn Latch (2-piece)
7 137125 1 Phase 4 OPL Non-Reversing Controller ONLY
137127 1 Phase 4 OPL Reversing Controller ONLY
8 112523 1 UniSport ® OPL Keyboard Label Assembly
* Used on UniSport ® dryers manufactured prior to March 13, 1989.
IMPORTANT: When ordering a replacement Phase 4 OPL microprocessor controller (computer) from the
ADC factory for UniSport ® option dryers, please advise the customer service representative
that the replacement microprocessor controller (computer) is to be preprogrammed with the
special UniSport
® parameters (programs).
