Direct Spark Ignition (DSI) Burner Assembly
Illus. No. Part No. Qty. Description
1 318104 1 Direct Spark Ignition (DSI) Burner Shield (3-Tube)
For Heat Reclaimer Models ONLY
318030 1 Direct Spark Ignition (DSI) Burner Shield (2-Tube)
For Non-Heat Reclaimer Models ONLY
2 150300 2 #10 x 1/2” Hex Washer TEK Screw
3 150309 2 #10-16 x 1/2” Hex Head TEK Crimptite Screw
4 128915 1 Direct Spark Ignition (DSI) Ignitor/Flame-Probe Assembly
880134 1 Ignitor/Flame-Probe Kit Assembly
(includes illus. nos. 4 and 6)
5 880330 1 High Voltage (HV) Wire and Connector Assembly
6 150103 2 or 3 #8-32 x 1/2” Phillips Pan Head Machine Screw
7 153000 2 or 3 #8 Steel Burr
8 151001 2 or 3 #8-32 Pal Nut
9 141105 2 or 3 Large Tube Burner ONLY
10 ---------* 2 or 3 Burner Orifice
(refer to Direct Spark Ignition (DSI) Burner Orifice Listing on page 57)
11 141232 1 1/2” Direct Spark Ignition (DSI) Manifold (3-Port)
For Non-Heat Reclaimer Models ONLY
141230 1 1/2” Direct Spark Ignition (DSI) Manifold (2-Port)
For Heat Reclaimer Models ONLY
12 318700 1 Pipe Bracket (bent)
13 150300 2 #10 x 1/2” Hex Washer TEK Screw
14 128927 1 1/2” 24 VAC Redundant (natural gas) Gas Valve
140411 1 1/2” Valve Liquid Propane (L.P.) Conversion Kit
15 881367 1 1/2” Union Shut Off with Tail Piece
16 142809 1 1/2” x 29-1/8” Pipe
17 150309 4 #10-16 x 1/2” Hex Head TEK Crimptite Screw
18 318700 2 Pipe Bracket (bent)
19 850852 1 Non-Heat Reclaimer Burner Box ONLY
850863 1 Heat Reclaimer Burner Box ONLY
--------* 1 Direct Spark Ignition (DSI) Burner Assembly
(refer to Direct Spark Ignition (DSI) Burner Assembly Specifications
on page 57)
20 880815 1 ADC Direct Spark Ignition (DSI) Module ONLY - 50/60 Hz
21 150300 4 #10-16 x 1/2” Hex Washer TEK Screw
--- --------** 1 Liquid Propane (L.P.) Conversion Kit
(refer to Direct Spark Ignition (DSI) Liquid Propane (L.P.)
Conversion Kit Listing on page 57)
--- 410001 1 1/2” Allen Wrench
* Consult factory for elevations over 2,000 feet.
** Burner orifices are not included and must be ordered separately.
