15
Telephone: (508) 678-9000 Fax: (508) 678-9447
Dual Timer Control Box Assembly
Illus. No. Part No. Qty. Description
1 122603 1 9-Pin Socket Connector ONLY
2 122701 9 Socket Terminal ONLY
122801 1 Pin/Socket Extraction Tool
3 150300 2 #10-16 x 1/2” Hex Washer TEK Screw
4 141403 1 Direct Spark Ignition (DSI) 24 VAC Transformer
(for use on gas models with Direct Spark Ignition [DSI] Only)
5 150309 2 #10-16 x 1/2” Hex Head TEK Crimptite Screw
6 131030 1 Steam Valve Relay (High Pressure Steam Only) - 120 Volt
131031 1 Steam Valve Relay (High Pressure Steam Only) - 208/230 Volt
7 131814 1 Motor Control Relay ONLY
(120 Volt controls Only)
8 150309 2 #10-16 x 1/2” Hex Head TEK Crimptite Screw
9 875250 2 In-Line Fuse Holder Assembly ONLY
(model application varies)
10* 136052 ** 4-Amp Fuse ONLY
136054 ** 15-Amp (Slo Blo) Fuse ONLY
136056 ** 20-Amp (Slo Blo) Fuse ONLY
11 136002 1 or 2 Panel Mount Fuse Holder Assembly ONLY
(model application varies)
12* 136052 ** 4-Amp Fuse ONLY
136054 ** 15-Amp (slo blo) Fuse ONLY
136056 ** 20-Amp (slo blo) Fuse ONLY
13 137013 4 Nylon Standoff
14*** 140150 1 Diode Logic Board
15 152002 2 #6-32 x 1” Phillips Round Head Machine Screw
16 120715 1 30-Position Terminal Block
120709 1 8-Position Terminal Strip
17 151000 2 #6-32 Pal Nut
* Check fuse rating for verification.
** As applicable.
*** For use on Globar
® dryer models ONLY.
