to the adapter and channel selected. See "

NVRAM settings

" on page 27 for information about the

NVRAM settings.
PCI information is displayed in the PCI Info tab.
The current status of the Configuration Tool is represented in the Status window at the bottom of the

display screen.
The About panel, selected from the About menu item in the Help tab, is an informational screen only.

The panel displays a list of components installed for the ATTO Configuration Tool and the tool's version

number.

NVRAM settings

NOTE:

The HP StorageWorks U320e SCSI Host Bus Adapter is designed to operate properly using factory

settings. Entering invalid or incorrect settings when using an NVRAM configuration utility, such as the

ATTO Configuration Tool, may cause your host adapter to function incorrectly.

CAUTION:

Back up system data before installing or changing hardware configurations.

Use caution when making changes to NVRAM settings and only make changes to those you are familiar

with. Once you have made the desired changes, click one of the following buttons:

Commit: activates the changes which take effect after rebooting your system.

Defaults: restores the adapter to factory default settings. The Commit button must be checked

to save any changes.

Restore: reverts to the NVRAM settings saved the last time the Commit button was used. Clicking

Commit is not necessary.

The upper part of the NVRAM Config panel contains common NVRAM settings that pertain to the entire

channel. The lower part contains settings that can be set for each SCSI ID on the channel.

Controller ID

Choices: 0–15
Default: 7
The adapter is normally set to SCSI ID 7 because ID 7 has the highest priority

on the bus. The setting should remain at ID 7 unless you are instructed to

change it by an HP Support representative.

Termination

Choices: Auto, High
Default: Auto
Set to Automatic unless there is a narrow SCSI cable connected to the

external connector.

Selection Timeout

(ms)

Choices: 1 ms — 1 sec
Default: 250 ms
Specifies the amount of time a device has to respond to being selected. The

time value can be lowered to speed up the boot process. If the value is

lower than the recommended 250 ms, some devices may not have enough

time to respond.

User guide

27
