Chapter 9: The A6 Modulation Matrix
A NDROMEDA A6 R EFERENCE M ANUAL 195
MOD BUTTONS WITH SINGLE DESTINATIONS
MODULE BUTTON TITLE
DESTINATION
PARAMETER
DESCRIPTION
ARPEGGIATOR SYNC/MOD TEMPO modulates the clock rate of the arpeggiator
SEQUENCER SYNC/MOD TEMPO modulates the clock rate of the sequencer
PORTA MOD PORTA RATE modulates the portamento rate
S&H MOD SAMPHOLD
RATE modulates the RATE of the Sample & Hold
OSC 1 PWM (Pulse
Width
Modulation) OSC 1 Pulse
Width modulates the pulse width of OSC 1’s square wave
OSC 2 PWM (Pulse
Width
Modulation) OSC 2 Pulse
Width modulates the pulse width of OSC 2’s square wave
PRE FILTER MOD OSC 1 LVL modulates the output level of OSC 1
MIX MOD SUB OSC 1 LVL modulates the output level of OSC 1’s sub oscillator
MOD RING MOD LVL modulates the output level of the Ring Modulator
MOD NOISE/EXT LVL modulates the output level of the noise module
and external input
MOD OSC 2 LVL modulates the output level of OSC 2
MOD SUB OSC 2 LVL modulates the output level of OSC 2’s sub oscillator
EFFECTS MOD (Analog
Distortion) DISTORT SEND modulates the level of the Analog Distortion SEND
control
POST FILTER MOD FILT1 LP LVL modulates the level of FILTER 1’s low pass output
MIX MOD FILT1 HP LVL modulates the level of FILTER 1’s high pass output
MOD FILT1 BP LVL modulates the level of FILTER 1’s band pass or
inverted band pass output
MOD FILT2 LP LVL modulates the level of FILTER 2’s low pass output
MOD SIN/RING VOL modulates the level of the unfiltered signals from
OSC 1 and OSC 2’s sine waves plus the RIng Mod
MOD BUTTONS WITH MULTIPLE DESTINATIONS
MODULE BUTTON TITLE
DESTINATION
PARAMETER
DESCRIPTION
LFO1 MOD PHASE
PULSE WIDTH
OFFSET modulates the PHASE, PULSE WIDTH or OFFSET of LFO
1
LFO2 and 3 MOD FREQUENCY
DELAY
AMPLITUDE
PHASE
PULSE WIDTH
OFFSET modulates the FREQUENCY, DELAY, AMPLITUDE,
PHASE, PULSE WIDTH or OFFSET of each LFO
EFFECTS DFX SEND LEFT,
RIGHT, L&R,
modulates the level of the Sends to the left and
right side of the Digital Effects module MOD (Digital
Effects)
PAN modulates the input pan of any Digital Effect that
has a Pan control (parallel configurations)
OSC 1 MOD 1, 2 and 3 FREQUENCY modulates the frequency of the oscillator
SQR WAVE LVL modulates the level of the square wave output
from the oscillator
PULSE WIDTH modulates the pulse width of the oscillator
OSC2->PWM modulates the amount of pulse width modulation
from Oscillator 2
