Chapter 5: Oscillators and Filters
A
NDROMEDA
A6 R
EFERENCE
M
ANUAL
129
DISPLAY
PAGE
PANEL LABEL
PARAMETER
DISPLAY
OPTIONS
or RANGE DESCRIPTION
FILT 1
or
FILT 2
ENV 2 AMOUNT
ENV2
0.00 ···
100.00
This parameter is used to set the amount of
Envelope 2 modulating the selected filter.
OFFSET
-100.00 ···
+100.00
This parameter sets the offset for
ENV 2
.
KEY TRACK
KEYTRK
-100.00 ···
+100.00
This parameter is used to set the amount of filter
tracking by the keyboard. At a setting of
50.00
,
the selected filter will be tracked by the keyboard
at “1 volt-per-octave” which is the same amount
as the VCOs. This means that the VCOs and the
selected filter will be tracked by the keyboard in
parallel. See page 121 for more details.
OFFSET
-127 ···
+127
This parameter sets the offset for
KEYTRK
.
Unlike the other offset, it is quantized in
semitones: if you want the filter to be an octave
lower when it's tracking the keyboard, set this to
–12.
FILT 1
(menu;
affects
both)
(none)
CV IN
0.00 ···
100.00
This parameter sets how much a control voltage
(if one is plugged into the
CV FILTER INPUT
jack on
the Andromeda's rear panel) will affect the filter
frequency of both Filter 1 and Filter 2, if the
filter's
CV SRC
is set to
EXT IN
. If
CV SRC
is set
to
OSC FM,
this parameter sets the amount the
filter will be modulated by the oscillator.
FILT 1
or
FILT 2
(none)
CV SRC
This parameter allows you to select either an external input
(typically from an external envelope generator) to modulate
the filter, or to FM modulate the filter by
OSC 1:
(OFF)
If you turn Soft Knob 8 full counter-clockwise, so
that neither of the following settings are
highlighted, there will be no effect on the filter,
regardless of the setting of the
CV IN
control.
EXT IN
When
EXT IN
is in reverse type in the
display, the filter may be controlled by a signal
plugged into the
CV FILTER INPUT
jack on the
Andromeda's rear panel.
FILTFM
When selected, the filter may be FM modulated
by the output of
OSC 1
and/or
OSC 2
. For
FILTFM to work, the oscillator's FILTFM output
must be enabled (on the Oscillator's
WAVE
page
/
FILTFM
parameter). The level of FM
modulation is affected only by the
CV IN
parameter, not by any setting of the
PRE
FILTER MIX
knobs. For more information, see
"What is FM?" earlier in this chapter.
