Chapter 5: Oscillators and Filters
A NDROMEDA A6 R EFERENCE M ANUAL 127
F ILTER P ARAMETER D ESCRIPTIONS
Although FILTER 1 and FILTER 2 perform quite differently, their display parameters
are similar in function if not in location.
Filter 1 Parameters
SOFT KNOB
PAGE TAB
1 2 3 4 5 6 7 8
FILT 1 FREQ RES ENV2 OFFSET KEYTRK OFFSET CV IN CV SRC
MOD1 SOURCE LEVEL OFFSET ENABLE DEST
MOD2 SOURCE LEVEL OFFSET ENABLE DEST
MOD3 SOURCE LEVEL OFFSET ENABLE DEST
Filter 2 Parameters
SOFT KNOB
PAGE TAB
1 2 3 4 5 6 7 8
FILT 2 FREQ RES INPUT ENV2 OFFSET KEYTRK OFFSET CV SRC
MOD1 SOURCE LEVEL OFFSET ENABLE DEST
MOD2 SOURCE LEVEL OFFSET ENABLE DEST
MOD3 SOURCE LEVEL OFFSET ENABLE DEST
