Chapter 3

79

Removing the Lower Case

1. To remove the lower case, remove the thirteen screws as shown here.

2. Remove the lower case from the main unit.

Removing the System Board

1. Disconnect the touchpad cable from the system board.

2. Gently, remove the touchpad cable.
