68

Removal and Replacement

Removing the Hard Disk Drive

1. Remove the screw of the hard disk module.

2. Slide the hard disk module out from its bay.

Disassembling the Hard Disk Drive

1. Gently, detach the connector from the hard disk module.

2. Remove the two screws on both sides of the hard disk module.

3. Remove the hard disk plate from the hard disk module.
