52 OSD Menu
Signal Information
Shows the signal information. When "Input signal selection" is "4K Input", information for the entire signal and each
input is displayed. Select a signal with the SET or
buttons according to the guide at top right corner of the menu.
SDI Signal DisplayPort Signal
Item Display Example Item Display Example
Channel
Input Configuration
Select Input Signal
Resolution
Picture Rate, I/P/PsF
SDI Payload ID
Video Standard
Sampling Structure
Bit Depth
Picture Rate
Scanning Method
Link Number
CH1
3G-SDI 1
4K Input
4096x2160
24.00P
85 07 80 05 (ID Number)
3G-SDI
4:4:4 RGB
10-bit
60.00
Progressive/Progressive
(Transport/Picture)
Single/Link_1 Channel
Input Configuration
Select Input Signal
Resolution
Horizontal Frequency
Vertical Frequency
Pixel Encoding
Color Depth
Matrix Gamma
RGB Range CH4
DisplayPort
4K Input
4096x2560
79.57 kHz
59.962 Hz
4:4:4 RGB
10-bit
sRGB
Full
System Information
Shows the video display status and network information.
Item Display Example
Display DP-V3010
Serial No. 000000000000
Firmware Ver. 010.0060.0110
Usage Time* 5 h
IP Address 192.168.0.1
Subnet Mask 255.255.255.0
MAC Address FF:FF:FF:FF:FF:FF
Display Controller CL-01
Serial No. 00000000
Firmware Ver. 4.0.0
IP Address 192.168.0.10
Subnet Mask 255.255.255.0
MAC Address FF:FF:FF:FF:FF:FF
* The "Usage Time" is not always "0" when you purchase the display due to factory inspection.
