Page 49

49
OSD Menu
System Settings
This menu is used to set the settings related to the main unit and display controller system.
Item
Setting Options (underline indicates factory default)
Network
Sets the main unit and display controller network settings.
Configure an IP
Address
Automatic: Configures an IP address automatically with DHCP/Automatic IP.
Manual: Configure an IP address and subnet mask manually.
Display
192.168.0.1
Display
Controller
192.168.0.10
Subnet Mask
255.255.255.0
Language
Sets the language of the OSD menu and messages.
English,
,
Display Function
Sets the function to assign to the F buttons of the main unit. Select an F button and assign a
function from the following list. The factory defaults for the main unit F buttons is as follow:
F1 :
Channel UP
F2 :
Channel DOWN
F3 :
Time Code (On, Off)
F4 :
Aspect Marker (On, Off)
The following functions can also be assigned:
Monochrome/Blue Only/Red Off/Green Off/Blue Off (On, Off)
Backlight Control(Local Dimming (High, Middle, Low), Global Dimming, Off)
Screen Scaling (Native Input Resolution, 200%, Automatic)
H Delay (On, Off)
V Delay (On, Off)
Backlight Scan (On, Off)
Safety Zone Marker 1, 2 (On, Off)
Center Marker (On, Off)
Grid Marker (On, Off)
Show OSD (On, Off)
Knob Lock (On, Off)
CDL Override (On, Off)
CDL Save to Memory
CDL Load from Memory
CDL Export/Import
Note
• When changing channels with "Channel UP/DOWN", the channels with "Input Configuration"
(
39) set to "–" are skipped.
• "H Delay"/"V Delay" can be set only for SDI signal.
• When "H Delay" is "ON", the image display position can be adjusted using the display
controller’s for video in 1280x720 / 24.00P, 25.00P, 30.00P format. Adjust with the menu
screen closed.
• When checking the blanking area using "H Delay"/"V Delay", an audio signal check can be
performed, however some data is not displayed.
• When "CDL Override" is turned "On", you cannot adjust the POWER, SATURATION, OFFSET,
or SLOPE.
• When the "Backlight Control" setting is switched using an F button, the information is applied
to "Backlight Control" in "Picture Mode". Likewise, when any marker settings are changed,
those changes will be applied to "Enable" under the currently selected "Marker Preset".
