30 Using the OSD Menu
■ Export/Import Main Menu Settings ( 48)
1. Press the MENU button to open the OSD menu.
2. Select "Function Settings"→"Settings Export/Import".
3. Select "Export" or "Import" with the buttons.
4. Select "Execute".
When the confirmation screen appears, select "OK". Export/Import starts.
Exporting
Select "Execute" to save the file "dinfo.dat" to the root folder. If the same file name already exists, it will be
overwritten.
Importing
Select "All" or "Main Menu Name" in "Settings" and then select "Execute" to import "dinfo.dat" from the root folder.
■ Export/Import ASC CDL Parameters ( 50)
1. Press the MENU button to open the OSD menu.
2. Select "System Settings"→"Display Controller Function".
Select the F button to configure and assign "CDL Export/Import".
3. Press the assigned F button and select "Export" or "Import" with buttons.
4. Select "Execute".
When the confirmation screen appears, select "OK". Export/Import starts.
Exporting
Select a file format ".ccc" or ".cdl" and then select "Execute" to save to the root folder.
Importing
Select a file with extension ".ccc" or ".cdl" from the root folder and then select "Execute" to import the file.
Reference
• When exporting, the file is saved automatically with the file name "cdl_000 to 999 (consecutive number)" and the selected
file format (e.g. cdl_000.ccc).
• Up to 1000 CDL import files are recognized.
• For ".cdl" format files, the settings of "Picture Mode" are exported in addition to CDL parameters. When imported, the
settings of "Picture Mode" will be applied.
• It may be convenient to assign the "CDL Save to Memory" to an F button from the "Display Controller Function" of the OSD
menu for channel switching ( 50). The temporarily saved content is erased when power is turned off.
