Video Configuration: Type of Recording, Resolution and Frame Rate
62
Selecting the Resolution
1 Open the [Resolution] submenu.
[ 4K/2K/MXF Setup] > [4K (4096/3840)] or [2K (2048/1920)] >
[Resolution]
2 Select the desired resolution and then press SET.
• Available resolution options depend on the system priority and
recording mode settings.
Selecting the Frame Rate
This procedure is not necessary for 24.00 Hz recordings because the
frame rate will automatically be set to [24.00P].
1 Open the [Frame Rate] submenu.
[ 4K/2K/MXF Setup] > [4K (4096/3840)] or [2K (2048/1920)] >
[Frame Rate]
2 Select the desired frame rate and then press SET.
• The available frame rates depend on the system priority, system
frequency, recording mode and resolution settings.
NOTES
• Onscreen displays representing the mode, resolution and frame rate
that you selected will appear on the upper right of the screen.
• For details on the signal output from the 3G-SDI terminals, refer to Connecting to a 4K- or 2K-Compatible
External Recorder (A 41). For details on the signal output from the other terminals, refer to Video Output
Configuration (A 139).
Available system frequency, system priority, recording mode, resolution, and frame rate settings
System priority
System frequency 59.94 Hz 50.00 Hz 24.00 Hz
Mode / Resolution
Frame rate
23.98P 29.97P 59.94P 25.00P 50.00P 24.00P
4K
RAW / 4096Ч2160 Ь Ь Ь Ь Ь Ь
HRAW/ 4096Ч1080 – – Ь – Ь –
4K1K RAW / 4096x1080 – – Ь – Ь –
RAW / 3840Ч2160 Ь Ь Ь Ь Ь Ь
HRAW/ 3840Ч1080 – – Ь – Ь –
[ 4K/2K/MXF Setup]
[4K (4096/3840)]
[Resolution]
[4096x2160]
[ 4K/2K/MXF Setup]
[2K (2048/1920)]
[Resolution]
[2048x1080]
* Depending on the country/region
of purchase.
[ 4K/2K/MXF Setup]
[4K (4096/3840)]
[2K (2048/1920)]
[Frame Rate]
[23.98] or [25.00P]*
