ENGLISH

11

PREP

ARA

TIONS

En

Before making connections

• Connect the AC cords of the unit and any external

equipment last, after finishing all other connections.

• Insert the plugs completely into the jacks. Loose

connections may produce a humming sound or other
noise interference.

• Refer to the instructions of the connected equipment.

CAUTION

Do not set "Dolby Digital" to "Bitstream", and "DTS" to
"Bitstream" in the setup menu when connecting to an

AV

receiver not equipped with a Dolby Digital decoder or DTS
decoder (with a coaxial connecting cord).
Merely attempting to play a DVD may cause a screeching
noise which could be harmful to your ears and damage
the speakers. In such a case, be sure to select "PCM" in
"Digital Out".

Before connecting, identify your type of audio equipment or

TV referring to the following chart.

Then, decide the connection

and the setup procedure accordingly

.

NOTES

• The unit cannot be connected to a

TV which is not equipped with a video input connector

.

• Use a commercially available stereo-monaural audio cord when connecting to a monaural

TV.

Audio system to be connected

None (only a TV is connected)

A stereo system or an amplifier

An AV receiver equipped with DTS decoder

Connection type

A

on page 12

B

on page 13

C

on page 14

D

on page 15

F

on page 17

E

on page 16

Input jack of equipment to

be connected to the unit

––––

Digital input jack

Analog audio input jacks (L/R)

Digital input jack

Analog audio input jacks (L/R)

Digital input jack

An AV receiver equipped with Dolby Digital decoder or a
Dolby Pro Logic decoder

CONNECTIONS

CONTINUE

NOTES

• If picture noise appears while playing copy-protected

DVDs, connect the unit directly to a

TV. Do not connect

through a VCR, TV/VCR, or AV selector .

• For speaker connection, refer to the instructions of the

AV receiver .

When your TV is equipped with an S-video input jack, see page 18.
When your TV is equipped with component video input jacks, see page 19.
