Ch. 4 Advanced Functions

Ad
va

Fu
nc
tion
s

If a P-touch (PTCOM) port is already
installed, click the Next button and con-
tinue with step 5 below.

If a P-touch (PTCOM) port is not already
installed, click the Add button. The Port
Name dialog box appears.

From the list of PTCOM ports, select the
port where the PT-9600 is connected
(“PTCOM1:” if the PT-9600 is connected to
the COM1 port, or “PTCOM2:” if the
PT-9600 is connected to the COM2 port),
and then click the OK button. In the Driver
Setup dialog box, click the Next button.

5 A dialog box appears, allowing you to

select the PTCOM port where the PT-9600
is connected.

Select “PTCOM1:” if the PT-9600 is con-
nected to the COM1 port, or “PTCOM2:” if
the PT-9600 is connected to the COM2
port, and then click the Next button. (On
Windows

Me, 2000 and XP, select the

port added in step 4.) A dialog box
appears, allowing you to check how the
installation will be carried out.

6 Check that the installation will be carried

out as desired, and then click the Next but-
ton. A dialog box appears, indicating that
the printer driver has been installed.

7 If the port where the PT-9600 is connected

supports a baud rate of 9600 bps, click the
Next button.
If the port where the PT-9600 is connected
does not support a baud rate of 9600 bps,
or if you wish to check the connection
between the P-touch and the computer,
select “Start up the Change Baud Rate Wiz-
ard.”, and then click the Next button. The
Change Baud Rate Wizard starts up.

To change the baud rate:

8 Select the serial port where the PT-9600 is

connected, and then click the Next button.
A dialog box appears, allowing you to
select the desired baud rate.
