2
Before Use
Optional Supply
Original card
Principal Parts
a LED indicator
This indicator lights up when the unit is turned on, and flashes when the USB card writer module is
communicating with the computer.
b Card slot
Insert an original card/embroidery card here.
c USB connector
Connect to the computer.
a
Note:
The only original cards that can be used with this USB card writer module are those like the one
enclosed or optional original cards of the same type.
b
Memo:
Additional blank original cards can be purchased through an authorized dealer.
a
Note:
Never remove an original card or unplug the USB cable while this indicator is flashing.
b
Memo:
• Since power is supplied to the USB card writer module through the USB connection to the
computer, there is no power supply cable or power switch.
• Be sure to keep original cards away from high humidity, direct sunlight, static electricity and strong
shocks. Furthermore, do not bend the cards.
a
c
b
