Setting Up and Registering the Handset Registering the Pocket Phone to a Dual Radio Module
MDW 9040 Wireless Pocket Phone Installation and Use, 503-801-190
Issue 2, February 2001
37
The LEDs on the radio module have the following meaning.
7
To exit any screen and move back to the previous screen, OR, if you do not want
to make any changes at this time, press the Softkey (
) below Back.
8
Proceed to the instructions in “
Mapping to the Correct Communications System
”
on
.
Registering the Second Zone of a Dual Zone Configuration
To register your handset with the radio modules to which it will be connected in a
dual zone configuration:
1
Follow the procedures in the previous section, “
” on
.
2
Select Zone 2 in Step 5 to register the handset with the other radio module with
which it will be associated for dual zone operation.
The following occurs:
•
The second radio module makes checks regarding the handset registration
request.
•
If there are no unexpected conditions, the associated base module and
handset communicate using special link-up signaling.
•
The handset displays a “Registration Completed” message to the user.
The LEDs on the radio module have the following meaning.
Flashing Power LED
Handset is in Registration Mode
for Line 1
Flashing Control LED
Handset is in Registration Mode
for Line 2
IMPORTANT NOTE: The radio module will NOT allow the registration
process to occur if there is anything preventing registration such as the radio
module actively communicating with a previously registered handset.
Flashing Power LED
Handset is in Registration Mode
for Line 1
Flashing Control LED
Handset is in Registration Mode
for Line 2
IMPORTANT NOTE: The radio module will NOT allow the registration
process to occur if there is anything preventing registration such as the radio
module actively communicating with a previously registered handset.
