Handset led guide pins – Avaya TransTalk MDW 9040 User Manual
Page 38
2
Installing the MDW 9040 Pocket Phone System
The Battery Charger
MDW 9040 Wireless Pocket Phone Installation and Use, 503-801-190
30
Issue 2, February 2001
Figure 11. Inserting the Handset into the Battery Charger
Removing the Handset
from the Handset
Cradle
To remove the handset from the handset cradle, lift it out.
