Raster Command Reference

- 41 -

5. Flow Charts

5.9 Normal Flow for Network (Standard TCP/IP port) Connection

With a network connection, print data from the operating system’s port monitor is simply sent as is.

When it prints 2 pages data

BUSY

Computer

(host)

Printer

Divide print data
into particular size,
and send it.

Receive data

Printing 1st page

End process for
printing 1st

Sending data for
2nd page

Sending raster data

Printing 2nd page

As one page data
receives in the
printer buffer, start
printing

As 2nd page data
receives in the
printer buffer, start
printing.

At host side, as sending
print data has completed,
the print job data is
erased.

The print job is treated to
be completion at printer
side

Printer buffer is
full

Sending raster data
