Raster Command Reference
- 15 -
2. Print Data
274
62 mm x 29 mm
2.4 " x 1.1 "
62.0 mm
732 dots
28.9 mm
341 dots
58.9 mm
696 dots
22.9 mm
271 dots
1.5 mm
18 dots
3.0 mm
35 dots
275
62 mm x 100 mm
2.4 " x 3.9 "
62.0 mm
732 dots
99.8 mm
1179 dots
58.9 mm
696 dots
93.9 mm
1109 dots
1.5 mm
18 dots
3.0 mm
35 dots
362
12 mm Dia
0.47 " Dia
12.0 mm
142 dots
12.0 mm
142 dots
8.0 mm
94 dots
8.0 mm
94 dots
2.0 mm
24 dots
2.0 mm
24 dots
363
24 mm Dia
0.94 " Dia
24.0 mm
284 dots
24.0 mm
284 dots
20.0 mm
236 dots
20.0 mm
236 dots
2.0 mm
24 dots
2.0 mm
24 dots
273
58 mm Dia
2.2" Dia
58.3 mm
688 dots
58.3 mm
688 dots
52.3 mm
618 dots
52.3 mm
618 dots
3.0 mm
35 dots
3.0 mm
35 dots
ID 7 8 9 10
273
19.64 mm
201 dots
53.9 mm
636 dots
14.0 mm
165 dots
47.9 mm
566 dots
*1 The number of dots in the table is for 300 dpi; it is difference in the high-resolution mode.
*2 Margins of 3 mm (1.5 mm × 2) horizontally and 3 mm (1.5 mm × 2) vertically are added to a diameter of 16 mm .
2.3.3 Feed amount
The feed amount (left and right margins) is defined below.
Type Minimum Margin Setting Maximum Margin Setting
Continuous length tape
3 mm
0.12"
35 dots 127 mm
5"
1500 dots
Die-cut labels
The length offset indicated in “(b) Die-cut labels” of “ 2.3.2 Page size ”
is used.
However, set
“0” as the value of the “specify margin amount”
command.
*1 The number of dots in the table is for 300 dpi; it is difference in the high-resolution mode.
2.3.4 Maximum and minimum lengths
The maximum and minimum lengths are defined below.
Type Minimum Length Maximum Length
Continuous length tape
12.7 mm
150 dots 1000 mm
11811 dots
Die-cut labels Fixed Fixed
*1 The number of dots in the table is for 300 dpi; it is difference in the high-resolution mode.
