Raster Command Reference
- 14 -
2. Print Data
(b) Die-cut labels
P r i n t a r e a
1
6
2
5
3
4
1
2
6
5
3
4
P r i n t a r e a
7
8
9
10
Number 1 Width 2 Length
3 Print area width (maximum printing width) 4 Print area length
5 Width offset 6 Length offset
7 Width offset of masked area 8 Length offset of masked area
9 Width of masked area 10 Length of masked area
ID Label Size 1 2 3 4 5 6
269
17 mm x 54 mm
0.66" x 2.1"
17.0 mm
201 dots
53.9 mm
636 dots
14.0 mm
165 dots
47.9 mm
566 dots
1.5 mm
18 dots
3.0 mm
35 dots
270
17 mm x 87 mm
0.66" × 3.4"
17.0 mm
201 dots
86.9 mm
1026 dots
14.0 mm
165 dots
80.9 mm
956 dots
1.5 mm
18 dots
3.0 mm
35 dots
370
23 mm x 23 mm
0.9" x 0.9"
23.0 mm
272 dots
23.0 mm
272 dots
20.0 mm
236 dots
17.1 mm
202 dots
1.5 mm
18 dots
3.0 mm
35 dots
358
29 mm × 42 mm
1.1" x 1.6"
29.0 mm
342 dots
41.9 mm
495 dots
25.9 mm
306 dots
36.0 mm
425 dots
1.5 mm
18 dots
3.0 mm
35 dots
271
29 mm x 90 mm
1.1 " x 3.5 "
29.0 mm
342 dots
89.8 mm
1061 dots
25.9 mm
306 dots
83.9 mm
991 dots
1.5 mm
18 dots
3.0 mm
35 dots
272
38 mm x 90 mm
1.4 " x 3.5 "
38.0 mm
449 dots
89.8 mm
1061 dots
35.0 mm
413 dots
83.9 mm
991 dots
1.5 mm
18 dots
3.0 mm
35 dots
367
39 mm x 48 mm
1.5 " x 1.8 "
39.0 mm
461 dots
47.8 mm
565 dots
36.0 mm
425 dots
41.9 mm
495 dots
1.5 mm
18 dots
3.0 mm
35 dots
374
52 mm x 29 mm
2 " x 1.1 "
52.0 mm
614 dots
28.9 mm
341 dots
48.9 mm
578 dots
22.9 mm
271 dots
1.5 mm
18 dots
3.0 mm
35 dots
