Raster Command Reference
- 23 -
4. Printing Command Details
(3) Media width and length
The media width and length is described in millimeters. 0～255 (0 to FFh)
(a) Continuous length tape
* Media Width: The tape width is indicated in millimeters.
* Media Length: Fixed at 00h
Media Media Width Media Length
12 mm 12 0
29 mm 29 0
38 mm 38 0
50 mm 50 0
54 mm 54 0
62 mm 62 0
(b) Die-cut labels
* Media Width: The width of the die-cut section is indicated.
* Media Length: The length of the die-cut section is indicated.
Media Media Width Media Length
17 mm x 54 mm 17 54
17 mm × 87 mm 17 87
23 mm × 23 mm 23 23
29 mm × 42 mm 29 42
29 mm × 90 mm 29 90
38 mm × 90 mm 38 90
39 mm x 48 mm 39 48
52 mm x 29 mm 52 29
62 mm x 29 mm 62 29
62 mm x 100 mm 62 100
12 mm Dia 12 12
24 mm Dia 24 24
58 mm Dia 58 58
