1. Cautions on Use

For safety purpose, following symbols are used in this manual.

The case that a user may receive fatal damage, electric shock, or severe burn injury when
the product is incorrectly used.

The case that a user may receive minor damage or the equipment may get damage.

Verify correct wiring before turning on electricity since incorrect wiring may cause an
equipment failure or a fire. Modification of this equipment may cause malfunctioning or
a fire. Do not add modification on this equipment.

Wiring: Do not use empty terminals for irrelevant purposes.
Operation: Do not use a sharp-pointed tool for operating keys.

- Hand over this operation manual to a person who actually operates the product.
- Do not reprint or duplicate this manual without permission.
- Content of this manual may be subject to modification without prior notice.
- We are not liable for any faults arising from misuse of the product.

Verification of the product
1) Verification of the model:

Refer the model name printed in the packing box to the order sheet.

2) Verification of accessories:

Instruction Manual (this manual)....................................... 1 copy
Mounting attachment ......................................................... 1 pc (for TTM-P4)
Mounting metal instrument................................................ 1 set (for TTM-P9)

3) Model

TTM-P4-0-R (relay output with optional ABE)
TTM-P4-0-P (SSR output with optional ABE)
TTM-P9-0-R (relay output with optional ABE)
TTM-P9-0-P (SSR output with optional ABE)

Prior to control operation
- Non-volatile memory is used for storing settings, which stays in the storage even when the power is cut.
- Three thermocouple types (K, J, and R) are provided for this product.
When you use the product, please match the thermocouple type with product setting.

Warning

Caution

Warning

Caution

This manual is related to the following products:
