Page 14

13
PID setting parameters
Description Initial
value
Character
PID No.
1 (cold)
3 (hot)
Setting range
□
Proportional band P
3.0%
3.0%
0.1 to 200.0 %
□
Integration time I
0 second
0 second
0 to 3600 seconds
□
Differentiation time D
0 second
0 second
0 to 3600 seconds
□
AT temperature setting
0
°
C 0
°
C
As per the PID range setting
PID range intermediate point 1
0
°
C
Between minimum and maximum in the
temperature setting range -50°C
PID range intermediate point 2
0
°
C
Intermediate point 1 to the maximum in the
temperature setting range
Alarm temperature setting mode parameters
Character
Description
Initial value
Setting range
Alarm output lower and
upper limits
Upper limit:
0
Lower limit:
0
-1999 to +9999
°
C
7. Setting and Display Ranges
Input type
Display range
Setting range
Thermocouple K
-40 to +132°C
0 to 1200°C
Thermocouple J
-31 to +850°C
0 to 800°C
Thermocouple R
-20 to +1755°C
0 to 1300°C
8. List of Types
T
T
T
T
T
T
T
T
M
M
M
M
−
−
−
−
P
P
P
P
①
①
①
①
−
−
−
−
0
0
0
0
−
−
−
−
②
②
②
②
① Size
Symbol Size
(mm)
4
48 x 48
9
96 x 96
② Control output
Symbol Output
type
R Relay
output
P SSR
output
* The following specifications are always selected.
1) Time signal output/alarm output
2) Operating signal output
3) DI (external input)
