background image

11

When the automatic tuning is complete, the
product will switch back to the automatic
tuning startup screen.
Automatic tuning possible even when locked

Set a differentiation time for PID No. 3 (hot)

Press the PATT./STEP key.

[RUN/RESET] key

[RUN/RESET] key

[RUN/RESET] key

Start the automatic tuning of PID No. 1
(cold).
Temperature setting for automatic tuning

Start the automatic tuning of PID No. 2
(medium).
Temperature setting for automatic tuning

Start the automatic tuning of PID No. 3
(hot).
Temperature setting for automatic tuning

Start the automatic tuning.

PV

 

SV

PV



SV

PV



SV

PV



SV

[A]

Press the PATT./STEP key.

Press the PATT./STEP key.

Press the PATT./STEP key.

* Changing the setting concerning the number of patterns will switch the settings for the temperature settings for

pattern parameters, time settings, and time signal selections for common parameters back to the initial settings.

Selecting time signals and alarm outputs



Action types (to be set by using the

▽ key)

Additional functions (to be set by using the

△ key)

 Nil (this selects a time signal)

 No additional functions

 Deviation upper and lower limit alarm

 Output held

 Deviation upper limit alarm

 Standby sequence

 Deviation lower limit alarm

 Output held + standby sequence

 Deviation upper and lower limit range alarm

 Absolute value upper and lower limit alarm

 Absolute value upper limit alarm

 Absolute value lower limit alarm

 Absolute value upper and lower limit range

alarm

⑦ Alarm temperature setting mode (The SET lamp lights.)

- This mode will set the alarm temperature.
- Use the PATT./STEP key to select an alarm output lower limit "" and an alarm output upper limit "

" (This may not be displayed depending on the type of action selected for an alarm output.)

* If no key is pressed for 10 seconds after the temperature setting is changed, then the product will switch

automatically to "reset mode."

PV



SV


