Page 18
18
5.2 Setting a data length
5.3 Setting a stop bit length
5.4 Setting a parity
5.5 Setting a BCC check
The BCC check is disabled.
Initial value of MODBUS (RTU):
Initial value of MODBUS (ASCII):
＊＊＊
Stop bit 1
Stop bit 2
No parity
Odd parity
Even parity
Data length, 7 bits
Data length, 8 bits
* The RTU mode settings come only in three types:
、
、
.
The ASCII mode settings come only in three types:
、
、
.
5.6 Setting a communications speed
While in the "Set a communications speed" screen on the preceding page, operate the ▲ and ▼ keys
to make the settings. The initial value is
.
＊＊＊＊
1200 BPS
2400 BPS
4800 BPS
9600 BPS
19200 BPS
5.7 Setting an address
While in the "Set a communications address" screen on the preceding page, operate the ▲ and ▼
keys to make the settings. The initial value is .
Setting range: 1 to 247 stations (It cannot be set to a 0.)
