Setra System Model 231RS - Manual (Page 3)

3
Contents
1.0 GENERAL INFORMATION 4
2.0 MECHANICAL INSTALLATION 5
2.1 Media Compatibility 5
2.2 Environment 5
2.3 Pressure Fittings 5
2.4 Mounting 6
2.5 Installation Procedures 6
3.0 ELECTRICAL INSTALLATION 9
3.1 Electrical Terminaltion
Wiring: 2-Wire, 4 to 20 mA and Remote Zero
9
3.2 Electrical Terminations
Wiring: 3-Wire, 0 to 5, 0 to 10, 1-5 VDC and Remote Zero
10
3.3 Remote Sensors Installation 11
4.0 CONFIGURATIONS 14
5.0 RETURNING PRODUCTS FOR REPAIR 15
6.0 WARRANTY AND LIMITATION OF LIABILITY 15
