Setra System Model SRH - Manual (Page 4)

4
Wiring 4 to 20 mA Output Units (2-wire / T0, T1 & T2)
Shield
TH2
TH1 / +V_TMP
RTN_TMP / +V_RH
RTN_RH / COM
+EXC
6 Earth Ground Connection
5
4
3 NC
2 RH (4 to 20 mA) Output
1 Vin
Thermistor/PRTD
Wiring 0-5 V/0-10 V Output Units (3-wire / T0, T1 & T2)
Shield
TH2
TH1 / +V_TMP
RTN_TMP/ +V_RH
RTN_RH / COM
+EXC
6 Earth Ground Connection
5
4
3 RH (0 to 5V/0 to 10V) Output
2 Ground
1 Vin
Note: Unit shipped in 0 to 5V Mode. Move jumper to right for 0 to 10V Operation
Selectable Outputs
Thermistor/PRTD
5V
10 V
H
Wiring 0-5 V/0-10 V Output Units (4-wire / T3 & T5)
Shield
TH2
TH1 / +V_TMP
RTN_TMP/ +V_RH
RTN_RH / COM
+EXC
6 Earth Ground Connection
5
4
3 RH (0 to 5V/0 to 10V) Output
2
Ground
1 Vin
Note: Unit shipped in 0 to 5V mode with Tspan set to 60°C. Move Tspan jumper to select
optional ranges.
Selectable Outputs
NC
Active Tmp (0-5V/0-10V )Output
5V
10 V
T
5V
10 V
H
40 50 60
Selectable Tspan
(°C)
