3.0 ELECTRICAL INSTALLATION
3.1 Wiring
Match your transmitter with the corresponding diagrams and set the jumpers and wire
accordingly. Ensure that all of the installation and wiring is in compliance with all national
and local codes. Use 18-22 AWG shielded, twisted pair, copper conductors.
Caution: Do not bundle transmitter wires with AC power wires. Shield must be connected to
earth ground for CE compliance.
Wall Mount
Connector/Jumper Locations - Inside cover
Duct and Outside Mount
Connector/Jumper Locations - Board Assembly/Duct Probe
