ROTRONIC HP23-AW-A - Manual (Page 16)

E-M-HP23-V2_13
Rotronic AG
Bassersdorf, Switzerland
Document code Unit
HygroPalm HP23-A / HP23-AW-A hand-held
indicator:
User Guide
Instruction Manual
Document Type
Page 16 of 37
Document title
© 2009-2012; Rotronic AG E-M-HP23-V2_13
Main Menu Menu Items
Submenu
Items
Selections or
Information
Notes
probe memory
Reset to
Factory Returns the probe to the
initial factory adjustment
Temp Adjust
Applies to
selected probe
connected to
HF5 or HF8 Acquired Points Lists the cal. points
present in the probe
memory (a max. of 2
points are shown) Additional Options:
o
Clear all cal. points
o Clear the last point
Acquire Ref Saves value measured by
probe 2 (HP23) as a cal.
point
Acquire Manual entry:
known reference
environment Saves value entered
manually as a cal. point
Adjust Adjusts the probe Effect depends on number
of calibration points in
probe memory
Reset to
Factory Returns the probe to the
original factory adjustment
Probe 2
Note: this section
applies only
when input 2 is
connected to one
of the following:
• HygroClip 2
probe
• Service
connector of a
device with
integral probe
(HF3, HF4, etc.)
See Probe 1
See Probe 1
See Probe 1
Input 2 is not designed for
connection to the service
connector of a HF5 or HF8
transmitter
Data Capture o Displays the names of
the 8 data bins
o Press on ENTER to
select the highlighted
data bin
View Data
o Shows the individual
data records
o Use the up and down
keys to navigate the
records
Summary
Shows the minimum,
maximum and average
values for the data bin
Clear Data Clears the data bin
