Name
Type
Interfac
e
Description
Module
Prozess_PPO…
…1
_
1
6
…2
_
1
6
…3
_
1
6
…4
_
1
6
…2
_
3
2
…4
_
3
2
scal_AV3
REAL
IN
Scaling of the actual bus value 3 entered in
parameter P545 or P543[-03]. This value is
multiplied by the contents of parameter P545
or P543[-03].
Example:
Similar to scal_AV1
X
X
AV_1
REAL
INOUT
Output of the calculated actual value 1 from
the frequency inverter
(scal_AV1 * actual bus value 1 from the FI)
X
X
X
X
X
X
AV_2
REAL
INOUT
Output of the calculated actual value 2 from
the frequency inverter
(scal_AV2 * actual bus value 2 from the FI)
X
X
X
X
AV_3
REAL
INOUT
Output of the calculated actual value 3 from
the frequency inverter
(scal_AV3 * actual bus value 3 from the FI)
X
X
Table 4: Process modules - Input parameters
Pos : 27 /Anl eitungen/ SPS - Baus tei ne/Pr ozessbaust eine/ Ausgangsparamet er [Pr oz ess baust ei ne] @ 1 \mod_1338370927455_388.doc x @ 26451 @ 3 @ 1
3.3.2 Output parameters
Name
Type
Interfac
e
Description
Module
Prozess_PPO…
…1
_
1
6
…2
_
1
6
…3
_
1
6
…4
_
1
6
…2
_
3
2
…4
_
3
2
ZSW:
WORD
OUT
Status word from the frequency inverter.
X
X
X
X
X
X
ready_start:
BOOL
OUT
Initialisation is complete, the loading relay is
in status ON, the output voltage is still
disabled.
X
X
X
X
X
X
run:
BOOL
OUT
The frequency inverter outputs a 'runnning'
message
X
X
X
X
X
X
fault
BOOL
OUT
Drive malfunctioning and out of order; the
frequency inverter goes to switch-on block
status if acknowledgement is successful. A
new positive flank must be generated at the
enabling output "rel_fwd" or "rel_rev".
X
X
X
X
X
X
warning
BOOL
OUT
The frequency inverter has generated a
warning. The drive remains in operation. An
acknowledgement is not required.
X
X
X
X
X
X
Bus_out10
BOOL
OUT
Only with SK 5xxE. For further details of the
function please refer to parameter P481 in
the frequency inverter manual
X
X
X
X
Bus_out13
BOOL
OUT
Only with SK 5xxE. For further details of the
function please refer to parameter P481 in
the frequency inverter manual
X
X
X
X
actual_para
INT
OUT
Actually used parameter set (1...4)
X
X
X
X
X
X
Table 5: Process modules - Output parameters
