8
Series 8000 Enclosures
Subracks
The subrack is a 19" wide frame having solid side panels and horizontal rails across the top
and bottom to hold the system modules in place. Use of a subrack enables you to install your
Series 8000 system into a standard 19" test equipment rack, or bolt it into a NEMA enclosure.
The subrack has a built in 120VAC/240VAC selectable power supply to provide +/-15VDC at 1
amp. The subrack also can be configured with either one or two MCD 8000 display modules
that have up to six selectable inputs. The display modules draw no current from the +/-15 volt
supply.
Full 19" Sub-Racks - 3U/84HP Instrumentation Subrack
Part Number Configuration
853705-000
No display meter, 12 available positions
853705-001 One display meter, 9 available positions
853705-002 Two display meters, 9 available positions
