30
Back Panel I/O and Labeling
Each back panel has terminal blocks used for I/O with special laser markings depending on
the cards installed in the rack. The half rack has one 12 position terminal block, the 3/4 and
full racks have two 12 position terminal blocks. The outputs are labeled to be consistent with
the table below where `x' refers to the channel number. Unfortunately, because of the density
of the outputs on the back plane vs. the available outputs on the terminal blocks all outputs
will not always be available on the terminal block. If you need a specific output not provided
on the back panel terminal block please call the factory for information. If you have a function
card not listed here please refer to the manual for the specific function card on terminal block
labeling information.
TB
Module label
Function
8200 CHx Signal out of measuring channel
GND Ground from measuring channel
8200HT CHx Signal out of measuring channel
GND Ground from measuring channel
VC8000 +Ix Hi side current out of measuring channel
-Ix Lo side current out of measuring channel
SP8000 SHx Hi set point OC output for CHx
SLx Lo set point OC output for CHx
CEx common emitter output for CHx setpoints
GHx Go set point high for CHx
GLx Go set point low for CHx
SC8000 x+/-x Summed Output
SHx Hi set point output for CHx
SLx Lo set point output for CHx
CEx common emitter output for CHx
DY8000 PPX Peak-to-Peak or Positive peak for CHx
NPX Negative Peak for CHx
RMx RMS for CHx
SHx Hi set point output for CHx
SLx Lo set point output for CHx
CEx common emitter output for CHx
Any GND Ground
+V +15 volt from internal supply or +15V input
-V -15 volt from internal supply or -15V input
Table 3 -- Terminal Block Labeling;
