13
Instrument Enclosure
The instrument case is a fully enclosed stand-alone enclosure for your series 8000 system with
a tilt bar to elevate the front of the case. The subrack has a built in 120VAC/240VAC
selectable power supply to provide +/-15VDC at 500 milliamp. The subrack also can be
configured with either one or two MCD 8000 display modules that have up to six
selectable inputs. The display modules draw no current from the +/-15DC volt supply.
1/2 rack enclosures - 3U/42HP Instrumentation enclosure
Part Number Configuration
853704-000 No display meter, 6 available positions
853704-001 One display meter, 3 available positions
3/4 rack enclosures - 3U/63HP Instrumentation enclosure
Part Number Configuration
853723-001
One display meter, 6 available positions
