9 EM1005
3.4. Angle-Pulse Output (TRD/TRH/TRS/605/705)
Output Pin B
Output Pin G
With drive on square socket or hexagon end direction of rotation CW
View A 1:
A 1
Drive Side
(TRD605 models)
View A 2:
A 2
Drive Side
(TRH605 models)
View A 3:
A 3
Drive Side
(TRS605/705 models)
Fig. 7: Angle-pulse output
Direction of
Rotation
Direction of
Rotation
Direction of
Rotation
