Agilent B2200 User’s Guide, Edition 4 5-15
SCPI Command Reference
Command Summary
Command Description
Bias Mode Commands
[:ROUT]:BIAS:CHAN:DIS:CARD card_number Bias-disables the specified card.
card_number: 0 or ALL for Auto Config,
1, 2, 3, 4, or ALL for Normal Config
[:ROUT]:BIAS:CHAN:DIS[:LIST] (@channel_list)
[:ROUT]:BIAS:CHAN:DIS[:LIST]? (@channel_list) Bias-disables the specified channels.
channel_list: Channels to bias-disable.
Query returns the status of the specified channels:
1 (disabled) or 0 (enabled).
channel_list: Channels to check.
[:ROUT]:BIAS:CHAN:ENAB:CARD card_number Bias-enables the specified card.
card_number: 0 or ALL for Auto Config,
1, 2, 3, 4, or ALL for Normal Config
[:ROUT]:BIAS:CHAN:ENAB[:LIST] (@channel_list)
[:ROUT]:BIAS:CHAN:ENAB[:LIST]? (@channel_list) Bias-enables the specified channels.
channel_list: Channels to bias-enable.
Query returns the status of the specified channels:
1 (enabled) or 0 (disabled).
channel_list: Channels to check.
[:ROUT]:BIAS:PORT card_number,bias_port
[:ROUT]:BIAS:PORT? card_number Specifies the input Bias Port for the specified card.
card_number: 0 or ALL for Auto Config,
1, 2, 3, 4, or ALL for Normal Config
bias_port: 1 to 14 or -1
Query returns the input Bias Port number for the
specified card.
card_number: Card to check. 0 for Auto Config,
1, 2, 3, or 4 for Normal Config.
[:ROUT]:BIAS[:STAT] card_number,state
[:ROUT]:BIAS[:STAT]? card_number Sets the bias mode for the specified card.
card_number: 0 or ALL for Auto Config,
1, 2, 3, 4, or ALL for Normal Config
state: ON / 1 (mode ON) or OFF / 0 (mode OFF)
Query returns the mode status of the specified card:
0 (OFF) or 1 (ON).
card_number: Card to check. 0 for Auto Config,
1, 2, 3, or 4 for Normal Config.
