3
2
1 NC
NO
C
Pin Header
(Other side)
Terminal
Block
Relay
Output Type: Isolated relay SPDT (single poll double throw), NO / NC
Max. Load: 8 amps (AC) @ 115 VAC, 220 VAC, 230 VAC
7 amps (DC) @ 30 VDC (resistive load)
Max. Voltage: 250 VAC, 125 VDC
Terminal Terminal Block Connections
1
2
3
Common
NO (Normally Open) contact
NC (Normally Closed) contact
Terminal Configuration
Junction Box (not supplied)
Earth Ground (green) Earth Ground (green)
Load Neutral (-)
Load Hot (+)
External
Equipment
Load
Common (-)
Hot (+)
1
2
3 NC
NO
C
(normally Closed Contact)
(normally Open Contact)
(common Contact)
F-2000-PC Board
3-position
Terminal Block
1.4 Model PC Circuit Board Wiring
CAUTION: DISCONNECT POWER SOURCE BEFORE SERVICING.
F-2000 Page 4
AC
1.5 Model PB Circuit Board Wiring
CAUTION: DISCONNECT POWER SOURCE BEFORE SERVICING.
Pin Header
(Other side)
Terminal Terminal Block Connections
1
2
3
Voltage input (+)
Switched output (NO/NC)
Ground (-)
Terminal Configuration
Jumper Settings Jumper
JP1
JP2
NC = Normally closed contacts
NO = Normally open contacts (default)
IN = Internal power
EX = External power (default)
Note: See above voltage limits
Jumper Configuration
NC NO
JP1
IN EX
JP2
3
2
1 G
OUT
V
Terminal
Block
NC NO
JP1
IN EX
JP2
Jumpers
Output Type: Non-Isolated contact closure switch, NO / NC
Max. Load: 100 milliamps (.10 amp)
Max. Voltage: 30 VDC if JP2 is set for external power.
15 VDC if JP2 is set for internal power and F-2000 is powered by plug-in transformer.
3 VDC if JP2 is set for internal power and F-2000 is powered by Batteries.
Max. Power: 3 Watts
Ground (-)
Switched Output (NO/NC)
Supply (+) (voltage input)
1
2
3
G
OUT
V
F-2000-PB Board
3-position
Terminal Block
