Built-in Limit Switches
Stroke / angle derived from positioner feedback
Standard Version (SJ2-N)
Code T (only to –20° C)
Security Version (SJ2-SN)
Code U
3-wire (SI2-K08-AP7/ PNP)
Code R (no Ex)
Micro Switches
Code V (no Ex)
Entry for Remote
Potentiometer
Code D
Materials
Control vanes
Aluminum
Transmission shaft
1 4571
Additional Equipment
Page 23
August 2014
POS-UM-00223-EN-02
