Page 10

Manual Local and Remote Settings
Actuator mode
linear or rotary actuator
Linear valve
left or right mounted
Rotary actuator
opening clockwise or counter-
clockwise
Characteristic of
setpoint
linear, equal percentage, invers-equal
percentage or custom (22 points)
Valve function
opens or closes with increasing
setpoint
Split range
free upper and lower values
Travel limits
free upper and lower values
Cutoffs
free upper and lower values
Stroke range
configurable
Temperature unit
configurable (°C or °F)
Autostart
- Endpoints
- Standard Autostart
- Enhanced Autostart
- Smooth response
- Fast response
Control
parameters
Determined during Autostart
Working range
Freely adjustable (for indication on
LCD
Manual
adjustment of
P-gain, I-time, T63-time and dead
band
Manual operation Manual input of setpoint to drive the
valve in steps of 12 5 % or 1 %
Pneumatic test
Function to test the pneumatic
output
Workshop
input and angle calibation
LCD language
dependent on version
LCD orientation
dependent on version
PROFIBUS-PA
Bus address
FOUNDATION
Fieldbus
Simulation, Switch from Link Master
to Basic Field Device
Software Supported Configurations
• By means of Hand Held Terminal (HART)
• PC by means of VALcare Software
• PC among others by means of PC20/ PC50 /IFDC
• I/A Series System and other DCSs
• Depending on the version, configurations can be
achieved by a non-contact, protocol-independent
infrared interface by means of IRCOM
Failure Handling
In case
of Single
Acting,
Safety
position at
Air supply failure
pressure y1 = zero
Electric power
failure
pressure y1 = zero
Failure of
electronics
pressure y1 = zero
In case of
Double
Acting or
spool valve
amplifier,
safety
position at
Air supply failure
pressure y1 = zero /
y2 = zero
Electric power
failure
pressure y1 = zero /
y2 = full air supply
pressure
Failure of
electronics
pressure y1 = zero /
y2 = full air supply
pressure
For all types
of amplifiers
(with FF H1
or Profibus
PA)
Failure of communication is recognized
by configurable watch dog with response
delay of 0 1 s to 24 h
Behavior
configurable as
pressure y1 = zero or
stop at last value or a
configured value
Diagnostic
report
via communication and local LCD
Historical
status
is set if alarm was activated at any time
(also just short alarms)
Reset
by acknowledging
Spool Valve Amplifier for Single and Double Acting
Application
Spool valve amplifier as option for the SRD991 can be
used with double acting actuator and also with single
acting actuator
In case of single acting application, one of the pneumatic
output must be closed:
• If y1 is used, y2 is closed and failure handling for Electric
power failure and Failure of electronics becomes y1=zero
• If y2 is used, y1 is closed and failure handling for Electric
power failure and Failure of electronics becomes y2=full
air supply
Functional Specifications
