SRD991 with Communication PROFIBUS-PA and
FOUNDATION Fieldbus H1
SRD991-xPxxxx or SRD991-xQxxxx
PROFIBUS-PA
Data Transfer According to PROFIBUS- PA profile class B
based on EN 50170 and DIN 19245 part 4
GSD File The actual file can be downloaded from
our homepage
Configuration
Local / Display See page 9
Software VALcare DTM
Hardware PC- or PCMCIA- interfaces from Softing
I/A Series
System
FBM 223 in combination with CP60
Other Control
Systems
All Profibus-PA- compatible, e g Siemens
SIMATIC PDM (Process Device Manager)
FOUNDATION Fieldbus H1
Data Transfer FF Specification Rev 1 4, Link-Master (LAS)
Certified
According To
ITK 4 01
Function
Blocks
PID, AO, Transducer, Resource
Certified
According To
ITK 4 6
Function
Blocks
PID, AO, 2xDI, 1xDO Transducer, Resource
Additional
Functionality
Flat Addressing
DD Files The actual file can be downloaded from
our homepage
Configuration
Local / Display See page 9
Software VALcare DTM or National Instruments NI-
FBUS configurator
Hardware FBUS-interfaces from National
Instruments (AT-FBUS and PCMCIA- FBUS)
I/A Series
System
FBM220 or FBM221 in combination with
CP60
Other Control
Systems
All FOUNDATION Fieldbus H1- compatible,
e g SMAR, Fisher Rosemount Delta-V,
Honeywell, Yokogawa, ABB
For both fieldbus devices
Input Signal Digital
Supply
Voltage
9…32V DC 1)
Max. Supply
Voltage
48V DC
Operating
Current
10 5 mA ± 0 5 mA (base current)
Current
Amplitude
± 8 mA
Fault Current Base current + 0 mA (base current + 4
mA by means of independent FDE-safety
circuit) according to IEC 1158-2
Operating
Values
According to IEC 1158-2
Startup Time
(Init Phase)
Approx 2 sec
Bus
Connection
Fieldbus interface based on IEC 1158-2
according to FISCO-Model
Power Supply Power supply is achieved dependant
on the application by means of fieldbus
power supply units or segment coupler
Electrical
Classification
See page 13
1) Data of ”Intrinsically Safe” version
SRD991 without Communication
SRD991-xDxxxx
Signal Input Two wire system
Reverse Polarity Protection Standard feature
Signal Range
4…20 mA
Operating Range 3 6…21 5 mA
Input Voltage 8 5…36V DC 1) (unloaded)
Load 00 Ohms, 6 V at 20 mA
With applications without communication the capacity
parallel to input may not be higher than 100 μF
Startup Time
Approx 3 sec
Interruption Time Without
Power Down
With LCD, typ 80 ms 2)
1) On request we can specify higher voltage limits
2) Worst case conditions 4-20 mA, with position feedback option, i/p-output with max
current
Configuration
Local / Display See page 9
Software VALcare (DTM)
Hardware per modem EDC82
Electrical classification See page 13
Safety Requirements
Page 15 August 2014 POS-UM-00223-EN-02
