SPECIFICATIONS
Physical
Installation
Mounts between 2 inch ANSI raised face flanges . Horizontal or vertical mounting
Flow Range/Nominal K Factors See pressure drop graphs
Low Range 7…70 acfm (10…100 mcfd)/365 pulses per acf (12,900 pulses per m 3 )
Mid Range 14…210 acfm (20…300 mcfd)/190 pulses per acf (6710 pulses per m 3 )
High Range 35…350 acfm (50…500 mcfd)/85 pulses per acf (3000 pulses per m 3 )
Working Pressure Vacuum to 2220 psig (15 .3 MPa)
Pressure Drop 3 inches of water column (7 .5 mbar) at maximum rated flow (dry air)
Pressure Port 1/8 inch NPTF (plugged)
Temperature –40…330° F (–40…165° C)
Electrical
Output Voltage
100 mVp-p minimum when used with Blancett B111113 magnetic pickup
Accuracy
Linearity
± 2% of reading over the specified measurement range
Uncertainty
± 1% of reading (when calibration data is entered into an intelligent Blancett
monitor/transmitter)
Repeatability ± 0 .5%
Certifications
Intrinsically Safe
Class I Division 1 Groups C, D
Entity parameters with Blancett B111113 magnetic pickup installed for US and Canada .
Complies with UL 913 and CSA 22 .2 No . 157-92
V
max
= 10V
I
max
= 3 mA
Ci = 0 µF
Li = 1 .65 H
Explosion Proof Class I Division 1 Groups C, D . Complies with UL1203 and CSA C22 .2 No . 30-M1986
Single Seal Complies with ANSI/ISA 12 .27 .01-2003
Construction
Body and Cartridge
316/316L stainless steel
Bearing Mounts 304 stainless steel
Set Screws – Pressure Port Plug 316 stainless steel
Bearings and Rotor Shaft Tungsten carbide
Rotor 410 stainless steel
Connections
Pickup
Mates with AN3106A-10SL
Conduit 1 in . NPT (25 .4 mm)
