Symbol explanations – Badger Meter QuikSert User Manual
Page 18
SYMBOL EXPLANATIONS
REFER TO ACCOMPANYING DOCUMENTS.
EXPLOSION HAZARD - SUBSTITUTION OF COMPONENTS MAY IMPAIR SUITABILITY FOR CLASS I, DIVISION 2.
DO NOT CONNECT OR DISCONNECT EITHER POWER OR OUTPUTS UNLESS THE AREA IS KNOWN TO BE NON-
HAZARDOUS.
MPORTANT
I
Not following instructions properly may impair safety of equipment and/or personnel.
Electrical Symbols
Function
Direct
Current
Alternating
Current
Earth
(Ground)
Protective
Ground
Chassis
Ground
Symbol
Turbine Flow Meter, B142 Gas QuikSert
Page 18
June 2014
