CERTIFICATE OF COMPLIANCE
The products listed below are eligible to bear the CSA
Mark shown with adjacent indicators ‘C’ and ‘US’ for
Canada and US or with adjacent indicator ‘US’ for
US only or without either indicator for Canada only.
CertificateE: 1667574 Master ContractE: 215035
ProjectE: 2428682 Date IssuedE: July 19,2011
Issued toE: Racine Federated Inc.
8635 Washington Ave
Racine, WI 53406
USA
AttentionE: William Roeber
PRODUCTS
CLASS 2258 04 - PROCESS CONTROL EQUIPMENT -Intrinsically Safe, Entity -For
Hazardous Locations
CLASS 2258 84 - PROCESS CONTROL EQUIPMENT -Intrinsically Safe, Entity --For
Hazardous Locations -Certified to US Standards
Class I, Div. 1, Groups C and D; Class II, Div. 1, Groups E, F and GE:
• Model 280605, Battery Powered B2800 Series Flow Monitor . Intrinsically safe when installed
per Drawing NO .B280001 and using Duraeell 1 .5 V D-cell (p/n MN 1300) or Energizer 1 .5 V (p/n
E95) . Opto-isolated entity parameters are Vmax = 30 V, Imax = 100 mA, Ci = 0 µF, Li = O . Output to
Turbine Flow Meter having Entity Parameters of Voc = 3 .5V ; Isc = 1 .8mA ; Ca = 15µF ; La = 1 .65H .
Temperature code T3C at maximum Ambient 70 °C . Enclosure Type 4X .
• Model B280606, Loop Powered B2800 Series Flow Monitor . Intrinsically Safe when installed per Drawing
No . B280002 . Opto-isolated entity parameters are Vmax = 30 V, Imax = 100 mA, Ci = 0 .0 µF, Li = 0 . 4-20 rnA
Current loop entity parameters are Vmax = 30 V, Imax = 100 mA, Ci = 0 .5 µF, Li = O . Output to Turbine Flow
Meter having Entity Parameters of Voe = 3 .5V ; Isc = 1 .8mA ; Ca = 15µF ; La = 1 .65H . Temperature code T3C
at maximum Ambient 70°C . Enclosure Type 4X .
DQD 507 Rev . 2009-09-01 Page: 1
