Airedale EcoChill 6kW - 46kW - Manual (Page 44)

44
EcoChill Chiller
Technical Manual 7300221 V1.1.0_02/2013
354
310
Ø 12.70 L
Ø 15.88 G
194.5
70
130
1000
900
650
330
Ø 9
895
122,50 122,50
Gx
Gy
16.1.9. ECL 030-040 C
holes for electric cables
gas
liquid
A
D
C
B
Mod. A B C D
VT9 40 30 23 M8
