EcoChill
Chiller
Technical Manual 7300221 V1.1.0_02/2013
16.1.5. ECL 030 - 040 °A/HA
190
100
428
384
1124
1015
OUT 1”¼
IN1”¼
67
OUT 1”¼
IN1”¼
660
229
229
1118
408
Gy
Ø 11
Gx
ECL
MOD. VERS. WEIGHTS CENTRE OF
GRAVITY
KIT
VT
Gx
Gy
030
°/H
A
103
180
327
9
040
°/H
A
103
180
327
9
A
D
C
B
Mod.
A
B
C
D
VT9
40
30
23 M8
