1. ALARM
When more than one alarm is active the ALARM button will illuminate red.
Pressing the ALARM button once will indicate information regarding any
active alarms.
Pressing the ALARM button twice will reset any active alarms.
Prg
2. PRG Pressing the PRG button will select the main navigation menu.
Esc
3. ESC
Pressing the ESC button will return the user to the main display screen
showing unit status.
4. UP
Pressing the UP button can either:
Scroll through the various display screens, providing the cursor is in the top
left position.
Increase the value of a set point adjustment.
5. ENTER
Pressing the ENTER button will confirm any set point adjustments and move
the cursor to the next available set point.
6. DOWN
Pressing the DOWN button can either:
Scroll through the various display screens, providing the cursor is in the top
left position.
Decrease the value of a set point adjustment.
1
2
3
4
5
6
