Controls
Addressing the Display Keypad
The address of the display keypad can be configured only after having connected the power supply, using
the RJ11 connection cable.
To access configuration mode, press the + + buttons together and hold them for at least 5 seconds; the
screen shown below will be displayed, with the cursor flashing in the top left corner:
To change the address of the display keypad (display address setting), press the button once: the cursor will move
to the address field (nn).
Use the or buttons to select the desired value, and confirm by pressing again. If the value selected is not
the same as the one saved previously, the screen shown below will be displayed, and the new value will be saved to the
permanent memory. If the field nn is set to 0, the terminal will communicate with the pCO board using “point-to-point”
protocol (not pLAN) and the field “I/O Board address: xx” will not be displayed, as it has no meaning.
