Page 39

Rem. D Status 1 Tuning ‘State_Tune1’
MSB
LSB
D7
D6
D5
D4
D3
D2
D1
D0
Bit no.
Name
Allocation
Status ‘0’
Status ‘1’
D0
OStab
Process at rest
no
yes
D1
Orun
Optimization run
off
on
D2
Oerr
Optimization result
Ok
error
D3...D5 ‘0’
always ‘0’
D6
‘1’
always ‘1’
D7
Parity
Parameter a. configuration data
General
(function no.: 0)
Code
Descr. R/W Type Description
Range
Rem.
B3
71 C100
R/W INT CFunc: Controller function
CType: Controller type
WFunc:set-point function
(T,H)
(Z)
(E)
0..xxyz
72 C101
R/W INT CMode:Controller output action
CDiff: x/x-w Differentiat.
CFail: Behaviour with sensor fail
CAnf: Start-up circuit
(T)
(H)
(Z)
(E)
0..wxyz
73 C700
R/W INT OMode:Optimization mode
OCond: Process at rest.
OGrp: Allocation group opt.
OCntr: Controlled adaptation mode
(T)
(H)
(Z)
(E)
0..wxyz
74 C180
R/W INT SWext: Source for Wext
(T) 0..x000
Set-point
Set-point processing(function no.: 1)
Code
Descr. R/W
Type
Description
Range
Rem.
B2
41 W0
R/W
FP
Min. set-point limit f. Weff
-999..9999
42 W100 R/W
FP
Max. set-point limit f. Weff
-999..9999
43 W2
R/W
FP
Additional set-point
-999..9999
44 Grw+ R/W
FP
Set-point gradient plus
>0..9.999
1)
45 Grw-
R/W
FP
Set-point gradient minus
>0..9.999
46 Grw2 R/W
FP
Set-point gradient W2
>0..9.999
Algo
Control algorithm (function no.: 3)
Code
Descr. R/W Type
Description
Range
Rem.
B2
41 Xsh
R/W FP
Neutral zone
0.2 .. 20,0 %
42 Tpuls R/W FP
Min. pulse length
0.1..2,0 s
(1)
43 Tm
R/W FP
Actuator response time
10..300 s
44 Xsd1 R/W FP
Switching difference signaller
0,1..9999 %
45 LW
R/W FP
Trigger point separation add. cont.
-999..9999
46 Xsd2 R/W FP
Switching difference add. cont.
0,1..9999 %
47 Xsh1 R/W FP
Neutral zone
0.0 .. 999.9%
48 Xsh2 R/W FP
Neutral zone
0.0 .. 999.9 %
Function block protocol
39
9499 040 50511
1) Datum has swich-off function; additional data value ‘-32000’
