4 Quick entrance
The disk enclosed in the engineering set includes the GSD file, project examples for a SIMATIC ® S5 / S7,
the type file and configuration examples for COM PROFIBUS. Communication with a KS800-DP can be
built up easily by means of the configuration and a project.
4.1 Quick entrance with S5
Test environment
The following components are required for the test set-up:
w Programming unit (PG740 recommended)
w Automation unit
- S5-115U, S5-135U or S5-155U with IM 308-C
w KS800-DP
w Engineering set (order no. 9407 999 09x11)
w Cable
- PROFIBUS cable automation unit / IM 308-C i KS800-DP
- programming unit i automation unit
4.1.1 Example of a test environment:
A KS800-DP with address 5 is to be connected to an IM 308-C via PROFIBUS-DP. Process data module B
is selected (8 process data channels and parameter channel). Data shall be transmitted in fix point format.
The I/O addresses in the S5 start with 0 in the P area.
g
Before taking the test environment into operation, ensure that the automation units do not contain user
software (“initial clear”). The same applies to the IM 308-C memory card.
Procedure:
w Establishing the communications
w Instrument configuration
- Adjust address 5 on KS800-DP (via coding switches or engineering tool) and connect it to the
network.
- Activate bus termination resistors at the controller connector and at the (S5) PLC connector.
w PROFIBUS network configuration
- Insert the disk (engineering set) into programming unit.
- Call up COM PROFIBUS and load example (A:\KS800dp\type\example\Demo308i.et2)
- Select the correct CPU type with IM308C.
- If necessary, adapt addressings and DP network and transmit them to the DP master (Ä Fig.: ).
w Load S5 program
- Insert disk (engineering set) into the programming unit.
- Call up STEP ® 5.
- Load program example, e.g. (A:\KS800dp\s5_fb\example.fix\...)
- If necesary, match the addresses for send / receive window (A-A/E-A in FB) and transmit them to
the automation unit.
- Switch automation unit to run
Quick entrance
9499 040 50511 22 990914
