Instruction manual
Alpha DO 2000
8.2 Specifications for Wall Mount Version
Electrical Data and Connections
Power requirements
80 to 250 V AC/DC
Frequency 48 to 62 Hz
Signal output Two 0/4 to 20 mA outputs for DO values and
temperature, galvanically isolated
Load max. 600
Ω
DO input screw terminals
Connection terminal 2x3-pin, 8-pin, 9-pin and 13-pin terminal blocks
Mains fuse 250 mA anti surge
Mechanical Specifications
Dimensions (L x H x W)
144 x 144 x 110 mm
Weight 950 g
Material PBT
Insulation
NEMA 4X, IP 65
8.3 Specifications for Panel Mount Version
Electrical Data and Connections
Power requirements
80 to 250 V AC/DC
Frequency 48 to 62 Hz
Signal output Two 0/4 to 20 mA outputs for DO values and
temperature, galvanically isolated
Load max. 600 Ω
DO input screw terminals
Connection terminal 3-pin, 9-pin and 19-pin terminal blocks
Mains fuse 250 mA anti surge
Mechanical Specifications
Dimensions (L x H x W)
175 x 96 x 96 mm
Weight 700 g
Material ABS
Insulation
IP 54 (front) / IP 40 (housing)
